STAR Missing

[Segwin 0]

Hello,

Used Simbrief to create a flight plan from KSFO to KORD. I got this message upon importing:

Nothing found for FYTTE7. Ignoring.
No waypoint before airway Q122. Ignoring flight plan segment.
Found airway Q122 instead of waypoint as first entry in en-route list. Ignoring.



I went to Navigraph Charts software and FlightAware to check and FYTTE7 is still active. I used Navigraph FMS data manager to update LNM but still has the same problem. I didn't try to check the other errors yet. Anything I need to do to correct this?



Thank you,



Terry







[albar965 1,040]

Can you post the full plan as it was shown in the LNM download dialog?

Alex

[albar965 1,040]

Quote

Route description: KSFO MOGEE Q122 VIGGR FYTTE7 KORD.
Flight plan from San Francisco Intl (KSFO) to Chicago-O'Hare Intl (KORD).
Distance without procedures: 1.619 NM.
Found 12 waypoints: KSFO MOGEE MACUS MCORD LCU BEARR KURSE ONL KATES VIRGN VIGGR KORD.
Found STAR: FYTTE7.

No problems with this one but I can only guess since you did not provide enough information. I need the "Route description".

Alex

[Segwin 0]

Hi Alex,

I believe this is what you wanted:

Flight successfully downloaded. Reading of route description successful.

Route description: KSFO N0458F350 NIITE3 MOGEE Q122 ONL DCT FOD DCT MYRRS FYTTE7 KORD KDTW.
Flight plan from San Francisco Intl (KSFO) to Chicago-O'Hare Intl (KORD).
Distance without procedures: 1,604 NM.
Found 5 waypoints: KSFO ONL FOD MYRRS KORD.
Found SID: NIITE3.MOGEE.
Found alternate airport KDTW.
Using cruise altitude 35,000 ft for flight plan.
Nothing found for FYTTE7. Ignoring.
No waypoint before airway Q122. Ignoring flight plan segment.
Found airway Q122 instead of waypoint as first entry in en-route list. Ignoring.



Looking at KORD FYTTE 7 is missing as well.

Thanks Alex.



[Segwin 0]

Here is the pic I tried to paste into the other post Alex. I tried the Insert image from URL but it didn't work - tried two different sites. I pasted the link here Alex.



https://imgbox.com/ghg9Owp6

Edited January 18, 2023 by Segwin

[albar965 1,040]

Thank you for the information.

No problems reading the string here:



10 hours ago, Segwin said:

Looking at KORD FYTTE 7 is missing as well.

I see the FYTTE7 star here using the LNM Navigraph update cycle 2213 or plain MSFS data. It looks like you use an outdated AIRAC cycle if you see an older STAR FYTTE4.

Check the shown AIRAC cycle in the scenery library menu of LNM. It has to match the one in SimBrief.

Alex
