A bit of progress today of MSFS periodic frame time spike detection. Turns out that the spikes are around, not at 1Hz, and can vary by+-0.2Hz. Also, on my system at least, it is really hard to get these spikes to trigger, with me having to resort to 1000+ TLOD to get it there, which often overflows my VRAM at that level even with 24GB available. Nonetheless, I seem to be able to detect the spikes, as evidenced in the following test log which shows TLOD increasing from 680 through to 900, at which point the spikes appear in the RTSS graph and are detected by the app: 2026-06-28 14:52:07.494 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 0, Periodic: False, AvgInterval: 0.00s, StdDev: 0.00 2026-06-28 14:52:08.513 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 0, Periodic: False, AvgInterval: 0.00s, StdDev: 0.00 2026-06-28 14:52:08.519 [INF] [ LODController:RunTick ] VRAM Limiting Inactive 2026-06-28 14:52:09.532 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 0, Periodic: False, AvgInterval: 0.00s, StdDev: 0.00 2026-06-28 14:52:10.549 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 0, Periodic: False, AvgInterval: 0.00s, StdDev: 0.00 2026-06-28 14:52:11.567 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 0, Periodic: False, AvgInterval: 0.00s, StdDev: 0.00 2026-06-28 14:52:11.572 [INF] [ LODController:UpdateVariables ] Mode:NFR FPS:30 Pri:TLOD+ 680 TLOD:730 TLODRng:50-2000 OLOD:200 AGL:16 FPM:0 GPU:53% VRAM:95% 2026-06-28 14:52:12.581 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 0, Periodic: False, AvgInterval: 0.00s, StdDev: 0.00 2026-06-28 14:52:13.602 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 0, Periodic: False, AvgInterval: 0.00s, StdDev: 0.00 2026-06-28 14:52:14.623 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 0, Periodic: False, AvgInterval: 0.00s, StdDev: 0.00 2026-06-28 14:52:15.643 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 0, Periodic: False, AvgInterval: 0.00s, StdDev: 0.00 2026-06-28 14:52:16.666 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 0, Periodic: False, AvgInterval: 0.00s, StdDev: 0.00 2026-06-28 14:52:17.690 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 0, Periodic: False, AvgInterval: 0.00s, StdDev: 0.00 2026-06-28 14:52:18.714 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 0, Periodic: False, AvgInterval: 0.00s, StdDev: 0.00 2026-06-28 14:52:19.733 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 0, Periodic: False, AvgInterval: 0.00s, StdDev: 0.00 2026-06-28 14:52:20.752 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 0, Periodic: False, AvgInterval: 0.00s, StdDev: 0.00 2026-06-28 14:52:21.770 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 0, Periodic: False, AvgInterval: 0.00s, StdDev: 0.00 2026-06-28 14:52:21.776 [INF] [ LODController:UpdateVariables ] Mode:NFR FPS:30 Pri:TLOD+ 752 TLOD:802 TLODRng:50-2000 OLOD:200 AGL:16 FPM:-0 GPU:60% VRAM:94% 2026-06-28 14:52:22.793 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 0, Periodic: False, AvgInterval: 0.00s, StdDev: 0.00 2026-06-28 14:52:23.815 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 0, Periodic: False, AvgInterval: 0.00s, StdDev: 0.00 2026-06-28 14:52:24.844 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 0, Periodic: False, AvgInterval: 0.00s, StdDev: 0.00 2026-06-28 14:52:25.866 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 0, Periodic: False, AvgInterval: 0.00s, StdDev: 0.00 2026-06-28 14:52:26.888 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 0, Periodic: False, AvgInterval: 0.00s, StdDev: 0.00 2026-06-28 14:52:27.906 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 0, Periodic: False, AvgInterval: 0.00s, StdDev: 0.00 2026-06-28 14:52:28.927 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 2, Periodic: False, AvgInterval: 0.00s, StdDev: 0.00 2026-06-28 14:52:29.949 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 1, Periodic: False, AvgInterval: 0.00s, StdDev: 0.00 2026-06-28 14:52:30.968 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 1, Periodic: False, AvgInterval: 0.00s, StdDev: 0.00 2026-06-28 14:52:31.988 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 1, Periodic: False, AvgInterval: 0.00s, StdDev: 0.00 2026-06-28 14:52:31.993 [INF] [ LODController:UpdateVariables ] Mode:NFR FPS:29 Pri:TLOD+ 852 TLOD:902 TLODRng:50-2000 OLOD:200 AGL:16 FPM:-0 GPU:55% VRAM:94% 2026-06-28 14:52:33.006 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 1, Periodic: False, AvgInterval: 0.00s, StdDev: 0.00 2026-06-28 14:52:34.024 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 3, Periodic: False, AvgInterval: 2.64s, StdDev: 2.45 2026-06-28 14:52:35.043 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 4, Periodic: False, AvgInterval: 2.15s, StdDev: 2.11 2026-06-28 14:52:36.063 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 5, Periodic: False, AvgInterval: 1.89s, StdDev: 1.89 2026-06-28 14:52:37.090 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 6, Periodic: False, AvgInterval: 1.76s, StdDev: 1.71 2026-06-28 14:52:38.111 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 5, Periodic: True, AvgInterval: 1.21s, StdDev: 0.08 2026-06-28 14:52:39.129 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 6, Periodic: True, AvgInterval: 1.12s, StdDev: 0.13 2026-06-28 14:52:40.148 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 7, Periodic: True, AvgInterval: 1.12s, StdDev: 0.13 2026-06-28 14:52:41.172 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 8, Periodic: True, AvgInterval: 1.12s, StdDev: 0.13 2026-06-28 14:52:42.199 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 9, Periodic: True, AvgInterval: 1.12s, StdDev: 0.13 2026-06-28 14:52:42.205 [INF] [ LODController:UpdateVariables ] Mode:NFR FPS:26 Pri:TLOD+ 908 TLOD:958 TLODRng:50-2000 OLOD:200 AGL:16 FPM:-0 GPU:59% VRAM:95% 2026-06-28 14:52:43.219 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 10, Periodic: True, AvgInterval: 1.12s, StdDev: 0.13 2026-06-28 14:52:44.240 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 10, Periodic: False, AvgInterval: 0.95s, StdDev: 0.34 2026-06-28 14:52:45.264 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 10, Periodic: False, AvgInterval: 0.96s, StdDev: 0.34 2026-06-28 14:52:46.284 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 9, Periodic: False, AvgInterval: 0.95s, StdDev: 0.34 2026-06-28 14:52:47.305 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 9, Periodic: False, AvgInterval: 0.97s, StdDev: 0.35 2026-06-28 14:52:48.323 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 10, Periodic: False, AvgInterval: 1.04s, StdDev: 0.36 2026-06-28 14:52:49.346 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 9, Periodic: True, AvgInterval: 1.20s, StdDev: 0.07 2026-06-28 14:52:49.353 [INF] [ LODController:RunTick ] VRAM Limited Hold Activated @ 96% 2026-06-28 14:52:50.364 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 9, Periodic: True, AvgInterval: 1.17s, StdDev: 0.10 2026-06-28 14:52:51.386 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 10, Periodic: True, AvgInterval: 1.17s, StdDev: 0.10 2026-06-28 14:52:52.405 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 9, Periodic: False, AvgInterval: 0.96s, StdDev: 0.38 2026-06-28 14:52:52.415 [INF] [ LODController:UpdateVariables ] Mode:NFR FPS:25 Pri:TLOD+ 942 TLOD:992 TLODRng:50-2000 OLOD:200 AGL:16 FPM:-0 GPU:59% VRAM:96% LTD 2026-06-28 14:52:53.430 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 9, Periodic: False, AvgInterval: 0.97s, StdDev: 0.39 2026-06-28 14:52:54.455 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 9, Periodic: False, AvgInterval: 0.98s, StdDev: 0.39 2026-06-28 14:52:55.479 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 9, Periodic: False, AvgInterval: 0.98s, StdDev: 0.39 2026-06-28 14:52:56.499 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 9, Periodic: False, AvgInterval: 1.02s, StdDev: 0.40 2026-06-28 14:52:57.522 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 9, Periodic: True, AvgInterval: 1.22s, StdDev: 0.01 2026-06-28 14:52:58.542 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 8, Periodic: True, AvgInterval: 1.22s, StdDev: 0.01 2026-06-28 14:52:59.563 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 8, Periodic: True, AvgInterval: 1.21s, StdDev: 0.01 2026-06-28 14:53:00.579 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 8, Periodic: True, AvgInterval: 1.22s, StdDev: 0.01 2026-06-28 14:53:01.601 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 8, Periodic: True, AvgInterval: 1.22s, StdDev: 0.00 2026-06-28 14:53:02.619 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 8, Periodic: True, AvgInterval: 1.21s, StdDev: 0.00 2026-06-28 14:53:03.630 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 9, Periodic: True, AvgInterval: 1.21s, StdDev: 0.00 2026-06-28 14:53:04.641 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 8, Periodic: True, AvgInterval: 1.22s, StdDev: 0.00 2026-06-28 14:53:05.653 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 8, Periodic: True, AvgInterval: 1.21s, StdDev: 0.00 2026-06-28 14:53:06.671 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 8, Periodic: True, AvgInterval: 1.24s, StdDev: 0.05 2026-06-28 14:53:07.690 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 8, Periodic: True, AvgInterval: 1.22s, StdDev: 0.06 2026-06-28 14:53:08.710 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 8, Periodic: True, AvgInterval: 1.22s, StdDev: 0.06 2026-06-28 14:53:09.730 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 9, Periodic: True, AvgInterval: 1.22s, StdDev: 0.06 2026-06-28 14:53:10.748 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 8, Periodic: True, AvgInterval: 1.23s, StdDev: 0.06 2026-06-28 14:53:11.768 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 8, Periodic: True, AvgInterval: 1.23s, StdDev: 0.06 2026-06-28 14:53:12.791 [DBG] [ ServiceController:UpdateAverageF ] Spikes: 8, Periodic: True, AvgInterval: 1.20s, StdDev: 0.03 What it looks like graphically when the spikes are steady state @ 966 TLOD. Anyway, a bit of progress but still far from being reliable.

I agree that would be useful. Despite nothing coming to mind right now of how to do that, I will keep thinking about a potential solution. At least we are now aware that when this issue occurs, backing TLOD down for that particular flight phase eradicates it. Edit: It turns out that the RTSS interface I am using does support frame time buffer dumps of the last 1024 entries, but it just wasn't enabled. I have managed to expose it to AutoFPS, which is good news. Turning it into something that can reliably interpret 1Hz spikes without being fooled by other spikes will be a bit trickier but should be possible. I'll keep you posted on any major progress I make.

AutoFPS does work on two asynchronous 1Hz cycles, one for the automation logic and one for the UI display updating, but I can get those 1Hz spikes in MSFS if I set the TLOD high enough, beyond what is settable in MSFS settings eg 1000, in the UserCfg.opt file and not have AutoFPS running. Also, if you are not seeing any changing values in AutoFPS when these spikes occur, which it looks like you weren't with your TLOD sitting at TLOD max and being displayed green, then AutoFPS is not injecting anything into MSFS and hence is likely not the cause. You are using FreeTLOD with a high TLOD max and a complex aircraft at a complex airport surrounded by complex photogrammetery, so I would say your AutoFPS settings are too aggressive for this scenario. I would be using TLOD Min 50 and TLOD Extra, not Free TLOD, here and limiting it to TLOD 100 (ie. x2 multiplier) for better results on the ground here. I'd have to think about this some more but my gut feeling is no as the app doesn't have access to 1% low FPS like RTSS can produce and I'm not sure how I would use this without dumbing down the experience for everyone for what is really an edge case that could easily be spoofed by quick view changes.

I set it in the VD PC app settings here: You can see I also adjust horizontal and vertical FOV tangent, as this is not visually noticeable to me and offsets some of the render resolution increase from the VDXR render resolution. Warning, setting VDXR render resolution to 150% in conjunction with all my other settings sees my GPU load and VRAM use in the region of 80-95%. While a 5080 is roughly the performance equivalent of a 4090, it only has two thirds the VRAM hence it is very likely my specific settings will overflow VRAM on any GPU with 16GB VRAM or less and make performance unacceptable. The point I am trying to make with posting my settings is that it is possible to even further improve the default visual quality of the Quest 3 for a given FPS target but it requires tuning those settings to your specific hardware and supporting apps. Even at default settings, the Quest 3 has very good image quality so I would not worry if your system is unable to push it much past that, particularly since it is in the region of diminishing returns. Oh and yes I use FFV in MSFS, set to the default 50.

I have a BoboVR S2 and originally used batteries with it until i got sick of having to charge everything. Now for flight simming I just use the S2 as a head strap and don't even put the battery on the back and instead run a 90 degree USB cable to the Quest 3 power port and plug that into a phone charger. I don't even turn the headset off, just letting it sleep when no in use and instantly powering back on when I put the headset on. I has been fine like that for over two years now.

I am not familiar with the Pimax eco system but it is entirely possible you are already super sampling because what many headsets call 100% render resolution is actually a super sampled resolution. Nonetheless, I would just leave it if you are happy with what you are currently getting visual quality-wise, especially since the Crystal is higher resolution to start with. I am pretty sure nVidia SmoothMotion is a 2D-only feature. I tried it myself a while back and while it doubles the FPS of the mirrored VR image on my monitor, it does not double it in the headset, which you can verify by turning on the FPS overlay in OpenXR Toolkit. The Crystal light does have Smart Smoothing and Lock to Half Framerate for motion smoothing but from what I have read and from what Pimax users I know have told me, it is not very good (stuttering and artifacts) and I don't know anyone that actually uses it.

I specifically mention render resolution just a few words before what you quoted. It is called super sampling, which is rendering the scene at a higher‑than‑native resolution and downscaling it to produce a sharper image while also helping in VR counteract barrel‑distortion stretching at the edges of the lenses. eg. even without the extra scaling I am using, default godlike render resolution in Virtual Desktop for the Quest 3 is 3072 × 3216 pixels per eye. I run it higher because I have spare performance capacity with my GPU and it slightly improves visual quality over godlike.

Render resolution != hardware resolution

I use a Quest 3 with the specs in my signature. It connects to my PC via a dedicated FAST5393LTE-A (dual-band Wi-Fi 6) router with the Quest 3 being the only device connected by Wi-Fi through Virtual Desktop (VD) and an Ethernet connection from it goes to my PC. This router is connected by Ethernet to another FAST5393LTE-A which in turn is connected to my fibre optic internet and supplies the Wi-Fi connection to many other devices in my house (10+). I get great VR results with this hardware setup. I run MSFS 2024 at default high graphics settings and DLSS 4.5 Balanced Preset M. I have VD set to max bitrate AV1, which it has no problem maintaining smoothly at all times, with godlike render resolution with 150% scaling, giving me roughly 4000x4000 per eye that, combined with my DLSS settings, gives about the best clarity possible from the Quest 3 while maintaining 40 FPS locked (to give 80 FPS with SSW) and up to 400 TLOD with AutoFPS. While you won't be able to run as high a render scale as I do with your hardware, and may even need to drop back to 36/72 FPS for consistent performance, you should still be able to get a good result with a Quest 3. Of course, there are other options out there with higher resolution panels, but the price and PC hardware requirements go up significantly. IMO the Quest 3 is excellent value for money, has the best motion re-projection I have ever used, and works very well on older, but still respectable, hardware.

If by "recovery" option, you mean something that resets all settings in the app, just rerun the installer, select Reset Configs then Update. Warning, this will reset all app profiles to default for MSFS 2020 and 2024, not just the current profile, so make sure you really want to do this. Start Max is shown here: It defaults to disabled, so if you are unaware of it you likely don't have it enabled. Just leave it unchecked and set a reasonable TLOD min and you should be right.

If you are using the Start Max option in the app, then yes your FPS could start lower because of the higher starting level of TLOD. If not using that option and your FPS drops, that implies your minimum TLOD is too high and should be no different than if you manually set this TLOD in MSFS without using this app. Dynamic Settings may not decrease your FPS because it is brutally fast at butchering both TLOD and OLOD, so choose your poison wisely.

A slight change to my recommended settings when using AutoFPS 0.5.1.0, not because of SU5 but because of recent changes to AutoFPS: For your particular configuration, I would try using an FPS cap setup and set max frame rate in MSFS to 30, dynamic settings to 30 and Fixed Target FSR3 FPS to 60 in FPS Sensitivity mode.

Notwithstanding that MSFS is quite happy to CTD all of its own accord and is therefore the most likely explanation. I see from the associated log you sent me via PM that you were changing a few AutoFPS TLOD Base and Top settings just before the CTD, the last of which was selecting Fixed as the TLOD Base option about 10 seconds before the CTD. These changes should have done nothing more than vary TLOD in MSFS, which the app does all the time anyway, so should not have been the cause of the CTD. I ran a test with your settings and attempted to recreate your final settings change sequence and was not able to trigger a CTD, despite changing AutoFPS settings repeatedly for a couple of minutes, so I do still think it is just coincidence that a CTD happened for you. FYI, I note that the last setting you tried to change was the TLOD Base option, which can only ever be set to Fixed when using Auto Target FPS, as at least one parameter must be fixed to vary the other. In the next version of the app, likely to be released as a test version when the SU6 beta makes an appearance, the TLOD Base option will be removed from the UI when you are using Auto Target FPS as Fixed TLOD Base is forced anyway. eg.

Your AutoFPS settings look fine to me. The only thing I would suggest is running GPU-Z as a companion app, so that GPU load and VRAM usage is reported to the app, then enable VRAM+ in the app to protect you from potential VRAM overflows. Instructions for where to download and how to configure GPU-Z correctly to work with the app are contained within the readme.

Your new screenshot still shows the app is set to FG 2X. Set it to Auto, then after loading into a flight, take a screenshot to show that you have correctly configured it. Also, you haven't told me what FG are you using and exactly where are you setting it. Please advise. Re: When FG is inactive, TLOD can still decrease (but not increase, as the FG inactive GPU load is not the same as the FG active load) if you are not achieving the NFR of the target FG FPS you have set. In your case, you have set 72 FPS for the target FG FPS, in which case 36 is the NFR of that when FG is inactive so if you get less than 36 FPS then your TLOD will drop. Is this what is happening? The only real way I can tell what is going on is by looking at your log. If you can extract a small snippet like I did above then you can post here, otherwise send me the contents of the whole log in a PM so as not to clutter up this discussion. BTW, you don't have to wait until you have finished a flight to extract the snippet. It is only an unlocked text file so you can do it while the app and your flight is running.
