GTN750 Anyone?

Recommended Posts

Help AVSIM continue to serve you!
Please donate today!

I'm wondering if anyone has successfully integrated the GTN750 into the Seneca?

The Seneca V instrument panel looks like it is more compatible with one (or two) GTN 650's. It has two GNS 430's which are supposed to have the same form factor as the GTN 650. But has Carenado released a GTN 750/650 VC installation package for the Seneca V as they have for the Navaho?

Share this post


Link to post
Share on other sites

I don't think so. I know some users have successfully put the 750 in the space for the 530 (I think it's a 530 might be a 430) on the Jetprop and some other add ons. That for me would be enough.

Share this post


Link to post
Share on other sites

The Seneca has 2 X 430 GNS units in the panel...



There is no way I know of, that you can get a GTN 750 in there..



It simply does not fit.

Share this post


Link to post
Share on other sites

The Seneca has 2 X 430 GNS units in the panel...



There is no way I know of, that you can get a GTN 750 in there..



It simply does not fit.

That answers that. Shame. I really wanted in it. After the C90 it's my favorite.



I wonder if I could add it to the right G600

Share this post


Link to post
Share on other sites

This is what I made up but I am failing at getting it over the G600 GPS, its the first time I try to add a GTN 750 into any VC



So far the issue I am having is the color pixelation on the FTN which has me a bit puzzled. the pop up works fine. The other issue is that I having a hard time keeping the PFD on the left.



Any tips anyone can offer?






[Window Titles]
Window00=G600
Window01=GPS 430
Window02=Toggle_Control
Window03=INFO
Window04=ENGINE SETUP
Window05=START
Window06=Flight1 Garmin GTN750 U1 - DO NOT MODIFY
Window07=Flight1 GTN Stack - DO NOT MODIFY


[VIEWS]
VIEW_FORWARD_DIR=-1.000, 0.000, 0.000



//--------------------------------------------------------
[Window00]
Background_color=0,0,0
size_mm=1024,1024
window_size_ratio=1.000
position=8
visible=0
ident=MAIN_PANEL
window_size= 0.500, 0.666
window_pos= 0.010, 0.310
no_luminous=1

gauge00=G600_PA34V!g600_configPA34V,  0,0,1,1
gauge01=G600_PA34V!G600,  0,0,1024,1024
gauge02=PA34V!ToggleCARG500,  0,0,1024,50


//--------------------------------------------------------
[Window01]
Background_color=0,0,0
size_mm=100
window_size_ratio=0.600
position=6
visible=0
ident=10010
window_size= 0.323, 0.320
window_pos= 0.525, 0.616
no_luminous=1
zorder=7

gauge00=CarenadoG430_3D_PA34V!GNS430_nc1,  0,0,528,310
gauge01=PA34V!ToggleCAR430,  0,0,512,30


//--------------------------------------------------------
[Window02]
Background_color=0,0,0
size_mm=500,261
position=0
visible=0
ident=796
window_size= 0.200, 0.200
window_pos= 0.020, 0.160
zorder=5

gauge00=PA34V!Control_windows,  0,0,500,261


//--------------------------------------------------------
[Window03]
size_mm=555,131
window_size_ratio=1.000
position=0
visible=1
ident=10020
window_size= 0.238, 0.100
window_pos= 0.020, 0.040

gauge00=PA34V!ToggleCARINFO,  10,10,400,100


//--------------------------------------------------------
[Window04]
Background_color=0,0,0
size_mm=600,653
position=3
visible=0
ident=10060
nomenu=1
window_size= 0.350, 0.500
window_pos= 0.000, 0.000

gauge00=GAUGEPA34V!StartWindowsAircraft,  0,0,600,653


//--------------------------------------------------------
[Window05]
Background_color=0,0,0
size_mm=600,653
position=5
visible=0
ident=10050
nomenu=1
window_size= 0.350, 0.500
window_pos= 0.000, 0.000

gauge00=GAUGEPA34V!StartWindows,  0,0,600,653


//--------------------------------------------------------
[Window06]
Background_color=0,0,0
size_mm=937,887
position=7
visible=1
ident=14401
window_size= 0.340, 0.580
window_pos= 0.660, 0.160
zorder=99

gauge00=F1GTN!GTN750,  0,0,937,887,UNIT1.POP


//--------------------------------------------------------
[Window07]
Background_color=0,0,0
size_mm=255,800
position=0
visible=1
ident=14400
window_size= 0.058, 0.243
window_pos= 0.000, 0.000
zorder=100

gauge00=F1GTN!GTNStack,  0,0,255,870


//--------------------------------------------------------
[Vcockpit01]
Background_color=0,0,0
size_mm=1024,1024
visible=1
window_size= 0.340, 0.580
pixel_size=1024,1024
texture=$Panel_1
window_pos= 0.660, 0.160

gauge00=G600_PA34V!g600_configPA34V,  0,0,1,1
gauge01=GAUGEPA34V!Gauge_Clock,  332,518,279,279
gauge02=PA34V_G600!GPS_G600,  0,0,2,2
gauge03=G600_PA34V!G600_update,  0,0,1,1
gauge04=G600_PA34V!G600_update2,  0,0,1,1
gauge05=CARSound_PA34V!CarSound,  0,0,1,1
gauge06=F1GTN!GTN750,  329,0,386,515,UNIT1.POP


//--------------------------------------------------------
[Vcockpit02]
Background_color=0,0,0
size_mm=512,512
visible=0
pixel_size=513,513
texture=$Panel_2

gauge00=CarenadoG430_3D_PA34V!GNS430_nc1,  0,0,512,256
gauge01=CarenadoG430_3D_PA34V!GNS430_nc2,  0,257,512,256
gauge02=PA34V!ToggleCAR430,  64,0,256,32


//--------------------------------------------------------
[Vcockpit03]
Background_color=0,0,0
size_mm=512,512
visible=0
pixel_size=513,513
texture=$Panel_3

gauge00=Radio_PA34V!RadioAudio,  0,0,512,99
gauge01=GAUGEPA34V!Gauge_Autopiloto,  0,100,512,119
gauge02=GAUGEPA34V!Radio_KR87_ADF,  0,219,512,106
gauge03=DIGTTRANS_PA34V!transponder,  0,327,512,130


//--------------------------------------------------------
[Vcockpit04]
Background_color=0,0,0
size_mm=512,512
visible=0
pixel_size=512,512
texture=$Panel_4

gauge00=GAUGEPA34V!Gauge_Anum,  0,0,384,177
gauge01=GAUGEPA34V!Radio_KDI572_DME,  0,178,302,118
gauge02=GAUGEPA34V!Gauge_CLOCK_DIG,  349,124,160,162
gauge03=GAUGEPA34V!Gauge_ENGINE_DIGVC,  0,297,384,153


//--------------------------------------------------------
[Vcockpit05]
Background_color=0,0,0
size_mm=1024,1024
visible=1
pixel_size=1024,1024
texture=$Panel_5

gauge00=GAUGEPA34V!Gauge_Anum_L,  0,519,1024,148
gauge01=GAUGEPA34V!Gauge_Anum_R,  0,669,1024,148



[Color]
Day=255,255,255
Night=225,117,89
Luminous=200,200,101

[Default View]
X=0
Y=0
SIZE_X=8192
SIZE_Y=6143

Share this post


Link to post
Share on other sites

It is a little bit more complicated than that...



In the VC, the GTN unit is addressed as



gaugeXX=F1GTN!GTN750VC,  X,Y,W,H,UNIT1

Share this post


Link to post
Share on other sites

It is a little bit more complicated than that...



In the VC, the GTN unit is addressed as



gaugeXX=F1GTN!GTN750VC,  X,Y,W,H,UNIT1

Trail and error I guess I cant think of anyway to easily map the x,y. Width and height is a bit simpler to solver.

Share this post


Link to post
Share on other sites

Trail and error I guess I cant think of anyway to easily map the x,y. Width and height is a bit simpler to solver.



X,Y are the coordinates of the upper left corner of the gauge.

Share this post


Link to post
Share on other sites

Yes but they are relative to the whole VC?



No, relative to the current "VCockpit" section

Share this post


Link to post
Share on other sites

Had to replace the G600 units.

Now GTN750 on the right and PFD from Learjet on the left side.

The left G600 caused the bad color pixelation with the GTN.









Original G600 popup still available (for setting autopilot etc.) by clicking on top right screw.



[Vcockpit01]

Background_color=0,0,0
size_mm=1024,1024
visible=1
pixel_size=1024,1024
texture=$Panel_1

gauge00=F1GTN!GTN750,  355,19,419,440,UNIT1.VC
gauge01=PA34V_G600!GPS_G600,  0,0,2,2
gauge02=CARSound_PA34V!CarSound,  0,0,1,1
gauge03=PA34V!ToggleCARG500,  0,0,1024,50
gauge04=lear_45!PFD,  43,14,340,495

Regards
Stefan

Share this post


Link to post
Share on other sites

Hi,great job! Just a question: do i need to have the learjet in order to do that and wich version please!

Thanks

Regards

Stefano

Share this post


Link to post
Share on other sites

Hi Wildtomcat...just a thing:you forgot to tell to copy the folder Lear_45_XML from the Learjet 45 panel subfolder into the Carenado PA 34 Panel subfolder and the gauge04 gotta say:Lear_45_XML!PFD...................otherway your mod won't work at all. :fool:

thanks for your input and work :wink:

regards

stefano smania

Share this post


Link to post
Share on other sites
